The CM family of ceiling mount occupancy sensors provide a range sensor solutions for applications with finished ceilings.

Features

• Color: White
• Mounting: Single-Gang or Octagonal Box, Surface Mount
• Coverage Type: Large Motion 360º
• Detection Technology: Dual Technology (PIR/Microphonics)
• Relay: Dual Relay
• Voltage: 120/230/277VAC
• Configurable using the Sensor Switch Mobile App
• 360° coverage pattern
• Push- button programmable, adjustable time delays, and multiple operating modes
• 100 hr lamp burn-in timer
• No field calibration or sensitivity adjustments required
• Convenient test mode
• Green LED indicator

Dimensions

• Diameter: 4.55"

• Height: 1.55"


Warranty

• 5-Year Limited Warranty
