100005506 CompAir Delcos 3100 PN: 100005506 Standard Air Compressor Controller

CompAir Delcos 3100 PN: 100005506 Air Compressor Controller

 Intelligent control algorithms incorporate low level safe control voltages, efficient pressure transducer control with clearly annunciated softstop and energy-saving idle run functions.



The CompAir Delcos 3100 PN:100005506 Air Compressor Controller has an Informative clear text display available in 17 languages that informs the operator of Internal pressure, Compressor air/oil temperature and Mains pressure as well as Fault information complementing Fault LEDs.











3 Level Indication of fault condition via text display and LEDs





Warning (compressor is still running)





Shutdown (compressor stopped)





Maintenance required (compressor is running)











Operating status indication by LED display





Compressor running





Compressor in stand-by





Compressor enabled to start automatically after power loss





Compressor on remote control











Remote control





Remote load / idle run control (Sequence control systems and PLC monitoring)





Remote on / off control (Optional coupling relay isrequired for wiring lengths >20m



Communication





DELCOS 3100 Monitoring via a RS485 communication port for control of external modules and master/slave compressor configurations.











Codes





The CompAir Delcos 3100 PN: 100005506 Air Compressor Controller has Set-up codesfor each compressor configuration along with 3 Option choices which





allow you to custom configure parameters to the compressor.









Access code protection prevents unauthorised adjustment of operating parameters and settings











Protections





Protection of the compressor by self-circuit test





Compreessor Motor is prevented from starting if the internal pressure is higher than 0.8 bar





Over current protection for fan motor.





Pressure Protection





Temperature Protection











Automatic restart after power loss





The CompAir Delcos 3100 PN: 100005506 Air Compressor Controller has a selectable automatic restart capability after short power loss of up to 1,5 sec





100005506 CompAir Delcos 3100 PN: 100005506 Standard Air Compressor Controller
  • Default

$ 87.18

$ 67.06
